2-748 LINE – OIL PRESSURE AW 1 7/8 20 G – OIL TEMP U.S. GAUGE CO 1-2435 CABLES – MAGNETO TO IGNITION SWITCH 1-2439 DRIVE SHAFT – AC TACHOMETER U1-670-3 CABLE – THROTTLE CONTROL 3-536 STIFF INSIDE • 3-537 STIFF OUTSIDE 4-578 FIRE WALL ASSEMBLY 7-442-5 AIR SPEED INDICATOR 2-745 CONTROL – CARB HEAT 5-584 FIBERGLASS SOUNDPROOFING MS35206-246 SCREW • 8 REQ. NAS1149FN832P WASHER • 8 REQ. 2-749 BRACE – FLOOR BOARD • 2 REQ. 5-158L BOARD – LEFT FRONT FL

NAS1149F0332P WASHER • 2 REQ. AN380-2-2 COTTER • 2 REQ. U1-670-3 CABLE – THROTTLE CONTROL 1-2486 CABIN HEATER CONTROL TACHOMETER ALTIMETER OIL TEMPERATURE INDICATOR 5-150 INSTRUMENT PANEL 1-2548 PLATE – MAX AIR SPEED OIL PRESSURE INDICATOR 1-788 PRIMER COMPASS 1-2614 DEVIATION CARD HOLDER #4X1/4 SCREW – RD. HD. “PK” AIR SPEED INDIC.

AN520-416-10 SCREW MS21044N4 NUT #4X3/8 SCREW TYPE “A” “PK” AN515-B8-28 SCREW AN365-B832 NUT AN515-B8-16 SCREW AN365-B832 NUT AN515-8-12 SCREW 3-539 PANEL – CENTER DOORWAY 3-540 PANEL – REAR DOORWAY 3-449 CUSHION – FRONT SEAT BOTTOM 3-485 COVER – AILERON BELL CRANK #4X3/8 SCREWS TYPE “A” STV HD “PK”

7-438-1 RUBBER CONNECTOR 1-2435 CABLE – MAGNETO TO IGNITION SWITCH 1-2373 SHAFT – THROTTLE CONTROL CONNECT

3-546 LEFT SIDE PANEL

5-182 RETAINER TOP-REAR WINDOW AN515-6-5 SCREW • 5 REQ. A410-632 NUT • 5 REQ. U3-460 ASSEMBLY ENGINE CONTROL BOX 2-745 CONTROL CARB HEAT 1-2448 SWITCH IGNITION 1-2575 CLAMP MS35206-246 SCREW 1-2375 ESCUTCHEON – THROTTLE 1-596 KNOB – THROTTLE CONTROL AN23-10 BOLT AN320-3 NUT AN380-2-2 COTTER PIN U2-715 ARM – THROTTLE AN4-5 BOLT AN310-4 NUT AN970-4 WASHER AN380-2-2 COTTER PIN #4X3/8 SCREWS TYPE “A” STV HD “PK” AC301B-18-5 NAILS 1-395 PLATE
