TABLE OF CONTENTS

Figure Figure Page Figure Figure Page
No. Title Fig. List No. Title Fig. List

SECTION IX SECTION X
POWER PLANT GROUP RADIO GROUP
49 Spinner and Propeller Installation 152 153 Antenna System Installation 180 181
*50 Hartzell Propeller Installation 156 157 Marker Beacon Installation 183 184
*51 Aeromatic Propeller Installation 158 159 Lear Radio Installation 185 186
*52 Cowl Assembly 160 161 Narco Radio Installation 188 189
*53 Engine Baffle Installation 162 163 Piper Radio Installation 191 192
**53A Cowl and Baffles Installation 165 166 Piper Automatic Locator (ELT) Installation 193 194
*54 Oil Radiator Installation 168 169
*55 Muffler and Stack Installation 171 172 SECTION XI
*56 Power Plant Installation 173 174 MISCELLANEOUS GROUP
**56A Power Plant Installation 177 178 Optional Equipment and Repair Kits 195
Decals 197

*Not used on PA-22-108.
**Used on PA-22-108 only.

ix
