Page 20 - Piper PA-16 Clipper Parts Catalog

PART NUMBER PER SHIP NOMENCLATURE PRICES
11745-00 1 Plate Assembly – Cabin Air Inlet NM!
-73451-003 2 Plate – Carburetor Airscoop Attachment 11.01
480-921 2 Plate – Name – (Piper) PAC #10079-00 NM!
U13663-000 1 Plate – Propeller – Spinner (rear of propeller) 202.29

750-772 1 Propeller – Aeromatic – F200 NM!
751-097 1 Propeller – McCauley – 1C90LM-7252 NM!
450-940 1 Propeller – Sensenich – 74FM52 (Wood) NM!
M76AM-2-50 1 Propeller – Sensenich – (Metal) 3187.23
750-839 1 Propeller – Sensenich – Skyblade – CS-2-FM-6 NM!
-71451-008 1 Rod – Engine Baffle Tie 5.69
U10487-000 2 Rod – Engine Baffle Tie – Right Side 21.56
-71451-004 2 Rod – Engine Baffle Tie 29.65
U10487-002 2 Rod – Engine Baffle Tie – Left Side Only 81.46
10490-00 2 Rod – Muffler Support NM!
-10836-002 4 Screw – Drilled Head Cap 2.03
-11955-002 1 Shroud Assembly – Muffler 1219.61
12334-00 1 Spinner Assembly – Propeller – with McCauley Propeller NM!
12416-00 1 Spinner Assembly – Propeller – with Sensenich Metal Propeller NM!
10246-00 1 Spinner Assembly – Propeller – with Sensenich Wooden Propeller NM!
Stud – Mixture and Carburetor Heat Control Attachment
U70371-003 2 29.12
(code no. 487-532)
10493-00 2 Spring – Muffler Support Rod (code no. 487-202) NM!
-12043-003 1 Stack Assembly – Exhaust – Right 1424.58
12043-02 1 Stack Assembly – Exhaust – Left NM!
U12330-004 1 Strap – Spinner Assembly – Sensenich Metal Propeller 65.31
12330-03 1 Strap – Spinner Assembly – With Mccauley Propeller NM!
12330-02 1 Strap – Spinner Assembly – With Sensenich Wood Propeller NM!
-10415-003 2 Support – Baffle Hanger – Right Front Baffle 42.72
-10415-002 1 Support – Baffle Hanger – Right Front Baffle 37.78
U11417-000 1 Tailpipe Assembly – Exhaust 276.73
82332-30 1 Tube Assembly – ¼” Diameter – Oil Pressure Gauge Line NM!
AD2 39” Tube – 2 ⁄8” O.D. – Flexible – Aluminum NM!
1
-11957-000 1 Tube – Engine Breather 42.43
11963-00 1 Tube – Tailpipe Support (tailpipe to muffler attach clamp) NM!
11962-00 1 Tube – Tailpipe Support (tailpipe to stack) NM!
U80122-020 2 Washer – ¾ x .266 x .062 – Muffler Support Installation 7.39
-81342-019 1 Washer – ½ O.D. – Carb. Heater Installation 0.14
U85012-047 21 Washer – Fibre ½ x .191 x .062 – Cowl Installation 0.92

17
