415-14072-2 ERCOUPE ANGLE

415-14072-2-L ERCOUPE GUSSET - LEFT

Rear beam, lower inner end rib gusset, left hand Highlighted part in illustration

415-14072-2-R ERCOUPE GUSSET - RIGHT

Rear beam, lower inner end rib gusset, right hand Highlighted part in illustration

415-14074 ERCOUPE PLATE

Rear beam splice plate

415-14075-L ERCOUPE FLANGE - LEFT

Tip assembly flange, left hand

415-14075-R ERCOUPE FLANGE - RIGHT

Tip assembly flange, right hand

415-16005-1 ERCOUPE HINGE FITTING

415-16009-3-L ERCOUPE FITTING - LEFT

415-16009-3-R ERCOUPE FITTING - RIGHT

415-16009-4 ERCOUPE PIN

415-16017-2-L ERCOUPE REINFORCEMENT

415-16017-3-L ERCOUPE REINFORCEMENT - LEFT

Upper skin reinforcement, left hand

415-16017-3-R ERCOUPE REINFORCEMENT - RIGHT

Upper skin reinforcement, right hand

415-16017-4-L ERCOUPE REINFORCEMENT - LEFT

Aileron upper tip skin reinforcement, left Applicability: Ercoupe 415 series

415-16017-4-R ERCOUPE REINFORCEMENT - RIGHT

Aileron upper tip skin reinforcement, right Applicability: Ercoupe 415 series

415-16019-1-L ERCOUPE REINFORCEMENT - LEFT

Aileron upper tip skin reinforcement, left Applicability: Ercoupe 415 series
